• High quality Sandvick insert and pad
• Dia 25mm—65mm,first choose of high efficiency.
• Excellent straightness and surface finish.It can maintain good chip removal performance
• during the processing of stainless steel and low carbon steel,to keep continuous production.
• Easy to install and to use
| Dia range
mm |
insert | pad | drilling tube
0.D mm |
|||
| core insert | middle insert | outer insert | model | qty | ||
| 25.00-26.40 | 800-050308M-C-G | 800-050308M-I-G | 800-060308H-P-G | 800-06A | 2 | 22 |
| 26.41-28.70 | 800-050308M-C-G | 800-050308M-I-G | 800-060308H-P-G | 800-06A | 2 | 24 |
| 28.71-31.00 | 800-06 T308M-C-G | 800-050308M-I-G | 800-060308H-P-G | 800-06A | 2 | 27 |
| 31.01-33.30 | 800-06 T308M-C-G | 800-06 T308M-I-G | 800-08 T308H-P-G | 800-07A | 2 | 27 |
| 33.31-36.20 | 800-06 T308M-C-G | 800-06 T308M-I-G | 800-08 T308H-P-G | 800-07A | 2 | 30 |
| 800-08 T308M-C-G | 800-08 T308M-I-G | |||||
| 36.21-39.60 | 800-08 T308M-C-G | 800-08 T308M-I-G | 800-08 T308H-P-G | 800-07A | 2 | 30 |
| 800-09 T308H-P-G | ||||||
| 39.61-43.00 | 800-06 T308M-C-G | 800-08 T308M-I-G | 800-09 T308H-P-G | 800-08A | 2 | 35 |
| 43.01-47.00 | 800-10 T308M-C-G | 800-08 T308M-I-G | 800-09 T308H-P-G | 800-08A | 2 | 40 |
| 47.01-51.70 | 800-12 T308M-C-G | 800-08 T308M-I-G | 800-09 T308H-P-G | 800-10A | 2 | 43 |
| 800-10 T308M-C-G | 800-11 T308H-P-G | |||||
| 51.71-56.20 | 800-10 T308M-C-G | 800-08 T308M-I-G | 800-11 T308H-P-G | 800-10A | 2 | 45 |
| 800-12 T308M-I-G | 800-12A | |||||
| 56.21-65.00 | 800-12 T308M-C-G | 800-12 T308M-I-G | 800-11 T308H-P-G | 800-12A | 2 | 48 |
| 52 | ||||||
High quality Sandvick insert and pad
Dia 25mm---65mm,first choose of high efficiency.
E xcellent straightness and surface finish.It can maintain good chip removal performance during the processing of stainless steel and low carbon steel,to keep continuous production.
Easy to install and to use
| Dia range
mm |
insert | pad | drill ube 0.D
mm |
||||
| core insert | middle insert | outer insert | model | qty | vice qty | ||
| 25.00-28.70 | 800-050308M-C-G | 800-050308M-I-G | 800-060308H-P-G | 300604 | 2 | 1 | 22 |
| 28.71-31.00 | 800-06 T308M-C-G | 800-050308M-I-G | 800-060308H-P-G | 300604 | 2 | 27 | |
| 31.01-33.30 | 800-06 T308M-C-G | 800-06 T308M-I-G | 800-08 T308H-P-G | 400745 | 2 | 1 | 27 |
| 33.31-36.20 | 800-06 T308M-C-G | 800-06 T308M-I-G | 800-08 T308H-P-G | 400745 | 2 | 1 | 30 |
| 800-08 T308M-C-G | 800-08 T308M-I-G | ||||||
| 36.21-39.60 | 800-08 T308M-C-G | 800-08 T308M-I-G | 800-08 T308H-P-G | 400745 | 2 | 1 | 30 |
| 800-09 T308H-P-G | |||||||
| 39.61-43.00 | 800-06 T308M-C-G | 800-08 T308M-I-G | 800-09 T308H-P-G | 400805 | 2 | 1 | 35 |
| 43.01-47.00 | 800-10 T308M-C-G | 800-08 T308M-I-G | 800-09 T308H-P-G | 401006 | 2 | 1 | 40 |
| 47.01-51.70 | 800-12 T308M-C-G | 800-08 T308M-I-G | 800-09 T308H-P-G | 401006 | 2 | 1 | 43 |
| 800-10 T308M-C-G | 800-11 T308H-P-G | ||||||
| 51.71-56.20 | 800-10 T308M-C-G | 800-08 T308M-I-G | 800-11 T308H-P-G | 401206 | 2 | 1 | 45 |
| 800-12 T308M-I-G | |||||||
| 56.21-65.00 | 800-12 T308M-C-G | 800-12 T308M-I-G | 800-11 T308H-P-G | 401206 | 2 | 1 | 48 |
| 52 | |||||||
High quality Sandvick insert and pad
Dia 25mm---65mm,first choose of high efficiency.
Excellent straightness and surface finish.It can maintain good chip removal performance during the processing of stainless steel and low carbon steel,to keep continuous production.
Easy to install and to use
| Dia range
mm |
Holder &Insert | pad | drilltube | ||||||
| core holeder core insert | qty | middle holder
middle insert |
qty | outer holder
outer insert |
qty | model | qty | 0.D mm | |
| 60.01-63.50 | 15NDK
TPMT16T312R |
1 1 | 15ZDK
TPMT16T312R |
1
1 |
14WDK
R424.9-13T308 |
1 1 | 401206
(201006) |
2 1 | 52 |
| 64.00-67.00 | 15NDK
TPMT16T312R |
1 1 | 15ZDK
TPMT16T312R |
1
工 |
14WDK
R424.9-13T308 |
1
工 |
401206
(201006) |
2 1 | 56 |
| 67.20-68.00 | 15NDK
TPMT16T312R |
工
1 |
15ZDK
TPMT16T312R |
1
1 |
14WDK
R424.9-13T308 |
1
1 |
501407
(201407) |
2 1 |
56 |
|
68.20-72.00 |
15NDK
TPMT16T312R |
工
工 |
15ZDK
TPMT16T312R |
工 工 | 14WDK
R424.9-13T308 |
1
工 |
501407
(201407) |
2 1 |
61 |
|
73.00-78.00 |
15NDK
TPMT16T312R |
1
1 |
15ZDK
TPMT16T312R |
工 工 | 19WDK
R424.9-180608 |
1
1 |
501407
(201407) |
21 |
65 |
| Dia range mm | Holder &Insert | pad | drill tube
0.D mm |
||||||
| core holder core insert | qty | middle holder middle insert | qty | outer holder
outer insert |
qty | model | qty | ||
|
79.00-82.50 |
15NDK
TPMT16T312R |
1
1 |
15ZDK
TPMT16T312R |
工 工 | 19WDK
R424.9-180608 |
1 1 | 501407
(201407) |
2工 |
70 |
|
83.80-90.00 |
20NDK
TPMT220612R |
1
工 |
15ZDK
TPMT16T312R |
工
工 |
19WDK
R424.9-180608 |
工 工 | 501407
(201407) |
21 |
70 |
|
94.0-105.0 |
20NDK
TPMT220612R |
工
1 |
20ZDK
TPMT220612R |
1 1 | 19WDK
R424.9-180608 |
工 工 | 501407
(201407) |
2
1 |
80(100) |
|
106.0-120.0 |
15NDK
TPMT16T312R |
工
1 |
15ZDK
TPMT16T312R |
3
3 |
14WDK
R424.9-13T308 |
工 工 | 501407
(201407) |
21 |
100 |
|
125.00 |
20NDK
TPMT220612R |
1
1 |
15ZDK
TPMT16T312R |
3 3 | 14WDK
R424.9-13T308 |
1 1 | 501407
(201407) |
2
1 |
100 |
|
130.00 |
20NDK
TPMT220612R |
1
工 |
15ZDK
TPMT16T312R |
3
3 |
14WDK
R424.9-13T308 |
工
1 |
501407
(201407) |
2 1 |
100 |
|
140.0-150.0 |
15NDK TPMT16T312R |
1
1 |
15ZDK TPMT16T312R |
5
5 |
14WDK R424.9-13T308 |
1
1 |
501407
(201407) |
21 |
130 |
High quality Sandvick insert and pad
Dia 25m-5m,first chose of higheffcency.
Excellent straightness and suface fnish.It can maintain god chip removal performance during the processing o staines steland low carbon stel,tokeep continuous production.
Easy to insalland to use
| Diameter range
mm Dc mm |
Holder &Insert | Pad | ||||||
| core holder
core insert |
qty | middle holder middle insert | qty | outer holder outer insert | qty | model | qty | |
|
64.51-67.80 |
NDK17
C13T308-G |
工 工 | ZDK17
I13T308-G |
1
1 |
WDK19
P14T308-G |
工
工 |
401206
(201006) |
2 1 |
|
67.81-73.40 |
NDK17
C13T308-G |
1
1 |
ZDK17
I13T308-G |
1 1 | WDK19
P14T308-G |
1
1 |
401206
(201006) |
2 1 |
|
73.41-79.80 |
NDK17
C13T308-G |
1
1 |
ZDK17
I13T308-G |
1 1 | WDK23
P19T308-G |
1
1 |
501407
(201407) |
2 1 |
|
79.81-82.60 |
NDK17
C13T308-G |
工
工 |
ZDK17
I13T308-G |
1 1 | 14WDK
R424.9-13T308 |
1 1 | 501407
(201407) |
2 1 |
|
82.61-90.40 |
NDK24
C19T308-G |
1
1 |
ZDK17
I13T308-G |
工工 | 14WDK
R424.9-13T308 |
工
工 |
501407
(201407) |
2 1 |
|
90.41-106.0 |
NDK24 C19T308-G |
1 1 |
ZDK24 I19T308-G |
1 1 |
19WDK R424.9-180608 |
1 1 |
501407
(201407) |
2 1 |
Fasten alloy-coated insert and high-strength carbide pad,deep hole drill bit with replaceable tool holder.
A dded auxiliary guiding mechanism,processing is more stable and performance is better
Diameter 65.00---106.00 with higher working efficiency and More cost-effective
Outstanding hole straightness and surface finish.Good chip removal in the processing of stainless steel and low carbon steel to ensure uninterrupted production.
Easy to install and use.
